Bosch CM255B Solution Panel Unlock Reset Key - 1 Use Only

CM255B
Bosch Solution Panel Unlock Reset Key - 1 Use Only
FEATURES
• The Solution 6000 unlock key resets the install code and RAS access to 1234 and 12345678 respectively without defaulting any other programming.
• This is works even when the original installer has been locked out.
• This key can only be used ONCE.
• Selected Solution control panels include a software option that when selected will disable the factory defaulting option. If this option has been set, then you must know the current installer PIN code to access programming mode or to default the panel.
• Table 2 lists the current panels which support the CM255B default module.
• To determine of the panel has been factory default disabled, remove all power to the panel and then re-apply the power.
• If the on board relay pulses or clicks five times then defaulting has been disabled.
• In the field many situations arise where it is not possible to determine the current installer PIN code.
• Until now, the only remedy for this was to remove the control panel and return it to the distributor for factory defaulting. • Panel removal, transportation costs, Installer labour and the possibility of damage during transit make this is a costly exercise
• The CM255B factory default module has been designed to eliminate the need to un-wire the control panel or spend the time and money returning it to the factory for defaulting.

Compatibility
• Solution 16i (Complete Factory Default)
• Solution 16+ (Complete Factory Default)
• Solution 64 (Complete Factory Default)
• Solution 144 (Installer code & RAS Pin Defaulted Only)
