Nidac General Purpose Timer Relay - Series 3

CT1-TIMER
Nidac General Purpose Timer Relay - Series 3
FEATURES
The CT1 timer can be used for holding doors open for an extended duration or other applications beyond the sphere of access control.

4 Selectable Timing Ranges:
- 1 to 255 seconds in 1 second increments
- 10 to 2550 seconds (42½ minutes) in 10 second increments
- 1 to 255 minutes (4 hours, 15 minutes) in 1 minute increments
- 1 to 255 hours (10 days, 15 hours) in 1 hour increments

Accurate DIP switch timing selection (no pots)

Selectable Positive, Negative or Dual Edge trigger

Selectable Normally Open or Normally Closed trigger input

Heavy duty 5 Amp. change over relay

LED indication of relay operation

New size now suits Ritec/Hammond enclosure, NIDAC part HO-RL6105-F

14 Operating Modes:
- Single shot
- Single shot retriggerable
- Single shot cancellable
- Dual edge triggered single shot
- Dual edge triggered single shot retriggerable
- Bistable (clutch / toggle) operation
- Trigger Extension
- Maximum Pulse
- Minimum Pulse (retriggerable)
- Hold off (Door Open Too Long)
- Multi vibrator (strobe) with 1 second on time, selectable off time
- Multi vibrator (strobe) with equal on/off times
- Delay on
- Delay on retriggerable (no activity timer)
